The TrolMaster SCC-D is a solid, blank replacement front door for the SCC-1 and SCC-3 25-inch controller cabinets. With no pre-cut controller opening, it converts the cabinet into a fully enclosed, sealed housing, allowing compatible controllers such as the HCS-1, NFS-1, or CDA-1 to be mounted internally on DIN rails. It is also suited for secondary expansion cabinets where additional device stations and modules need to be housed without a front-mounted primary controller.
• SKU: SCC-D
• Compatible Cabinets: SCC-1, SCC-3
• Door Style: Solid, no pre-cut opening
• Enclosure Rating: IP56 / NEMA 4X equivalent
• Cabinet Form Factor: 25"
• Cabinet Dimensions: 25" L × 18" W × 6.26" H
• Compatible Controllers: HCS-1, NFS-1, CDA-1 and other internally DIN-mounted controllers
• Operating Temperature: 32–104°F (0–40°C)
• Primary Use: Sealed enclosure conversion and secondary expansion cabinet
• Mounting: Designed for internal DIN-rail controller mounting
• SCC-2 Compatibility: Not compatible; SCC-2 requires the separate SCC-D2 door
• Cabinet Included: No — replacement/addition door only
Key Advantage: The SCC-D provides a completely closed front panel with no controller cutout, making it ideal when the controller is mounted inside the cabinet or when an SCC-1/SCC-3 is being used as a secondary expansion enclosure while maintaining the cabinet's IP56 protection.
